Comfort that adapts to the room. Control that supports the building. We combine Mitsubishi Heavy technologies with calculated loads, suitable indoor units and a coordinated installation.
SCA Engineering is a dealer for Mitsubishi Heavy Industries VRF air conditioning systems. We support projects across Istanbul and the Marmara region through site survey, equipment selection, design, installation and commissioning.
Why Mitsubishi Heavy?
VTCC: respond to changing demand
Variable Temperature and Capacity Control adjusts target operating pressure according to indoor demand. Its practical value lies in the hours when rooms have different occupancy or load levels. We design the capacity distribution and operating schedule around that use. Actual energy consumption depends on the selected combination and conditions.
Explore KXZ2 controlCHCC: plan winter operation with usable capacity
Continuous Heating Capacity Control supports heating behaviour and capacity management around low outdoor temperatures and defrost. We assess it with the building’s winter heat loss and the model’s capacity at the design temperature. We do not treat this feature as the removal of every defrost event.
Airflex / Draft Panel: direct the air thoughtfully
Compatible cassette panels help reduce direct draught around occupants. We match the indoor unit, panel and controller, then plan vane direction around desks, seating and the room’s perimeter loads. The feature’s presence is confirmed through that complete combination.
Explore cassette comfortAuto E.S.P.: connect fan duty with duct resistance
Compatible FDU and FDUM units support automatic external-static-pressure control. We still calculate the duct duty, choose terminals and measure air distribution during commissioning. Automatic adjustment supports a correctly designed system; it cannot correct every duct or grille error.
Explore ducted-unit selectionRoom control and central management
We define local setpoints, operating schedules, permissions and any BMS requirement together. Central management, interfaces and consumption-allocation functions depend on compatible equipment. The selected control scope is identified in the project proposal.
Outdoor families for different project scales
Micro KXZ · 4–6 HP
Compact front-discharge equipment for villas, small offices and shops. Select the single- or three-phase suffix alongside simultaneous loads, outdoor airflow and the route to each room.
View Micro KXZKXZ Lite · FDC224 / FDC280
The FDC224KXZPE1 and FDC280KXZPE1 8–10 HP group combines a compact arrangement with 22.4 / 28.0 kW nominal cooling. The 2025 catalogue places it under Micro KXZ. Its own electrical, connection and piping limits apply.
View KXZ LiteKXZ2 · modular VRF
For offices, hotels and multi-zone buildings, select modules alongside part-load operation, winter performance, piping and controls. A two-pipe Heat Pump circuit and the separate KXZRE2 Heat Recovery family meet different mode requirements.
View KXZ2Indoor units: choose the air path and installation
- Mitsubishi Heavy Cassette Indoor Units
- Mitsubishi Heavy Concealed Ducted Indoor Units
- Mitsubishi Heavy Wall-mounted Indoor Units
- Mitsubishi Heavy Ceiling and Floor Indoor Units
Capacity is only one selection parameter. Ceiling depth, fan duty, occupied-zone air direction, condensate drainage and access determine whether the indoor unit works well in the finished room.
SCA catalogue
The updated SCA Mitsubishi Heavy catalogue covers KXZ2, Micro KXZ and KXZR2, with indoor units and controls. Use it alongside the model-specific technical guides to understand the complete system and the conditions attached to each selection.
Read the SCA Mitsubishi Heavy catalogueFrequently asked questions
Is SCA a Mitsubishi Heavy VRF dealer?
Yes. SCA Engineering supports Mitsubishi Heavy VRF projects through survey, selection, design, installation and commissioning in Istanbul and the Marmara region.
Are all technologies standard on every model?
No. Features depend on series, indoor-unit family, panel, controller and system configuration. Our proposal identifies the selected equipment and available functions.
Do I need a separate ventilation system?
We assess required outdoor air separately from room heating and cooling. A cassette fresh-air option or an AHU connection must be designed for the required quantity and conditioning load.
Plan your system with SCA
Share your floor plan, operating hours and preferred installation locations. Our Istanbul-based team supports projects across the Marmara region, from site survey and equipment selection to installation, testing and commissioning.
We coordinate the refrigerant circuit, electrical supply, drainage, ventilation and controls as one project. Your proposal identifies the selected models, accessories and installation scope.
Discuss your project Call SCA
